Screw sand classifier working principle, parameter

LXS series screw sand classifier is a sand washing equipment, which was designed to provide bigger capacity and higher cleaning level than traditional sand classifier. The input materials’ max size can be 30mm.

LZZG Screw Classifier Working Principle

The screw sand classifier is mainly composed of transmission device, spiral body, trough, lifting mechanism, lower support (bearing) and discharge valve.
The water tank of this machine is installed obliquely, and the inclination angle is determined according to the equipment configuration in the process flow. The transmission device drives the spiral to rotate in the tank. The slurry enters the tank from the side feed inlet, and a slurry settlement area is formed at the lower end of the tank. Its surface area and volume are determined by the inclination angle of the tank and the height of the overflow weir. The low-speed rotating spiral can play a certain stirring effect.



sand classifier working principle

The solid particles are different in size and density, so the settling speed in the liquid is different. The fine ore particles float in the water and overflow. The coarse ore particles sink to the bottom of the tank and are pushed upward by the screw.

screw sand washer

Technical parameters

Model capacity(m³/h) Water consu-mption (m³/h) Spiral diameter (mm) Tank length (mm) Feed size (mm) Motor Power (kw) Weight (kg) Dimension (mm)
LXS920 30-100 10-80 920 8016 ≤10 11 4270 8715*1632*2075
2LXS920 60-200 20-160 920 8016 ≤10 11*2 7580 8715*2602*2075
LXS1120 40-120 20-150 1120 8532 ≤10 18.5 5560 9231*1833*2126
2LXS1120 80-240 40-300 1120 8532 ≤10 18.5*2 10000 9231*2995*2126

If you are a user of spiral sand classifier, or if you have any problems with the use of sand processing equipment, we will provide you with relevant professional solutions for free!
