After the river sand is mined, it is inevitably doped with impurities such as soil and particles, and the river sand is of low quality. A sand washing plant is needed to achieve simple river sand cleaning, fine sand recovery, and wet sand dehydration. The overall structure of the LZZG water washing sand equipment is simple, it occupies a small area, it is also very convenient to install, and the operation is simple. The reliable design of the transmission part makes it effective to reduce the failure rate, and it can maintain a high operation even under harsh environmental conditions. effectiveness. The bucket sand washer has a simple structure, less wearing parts and small floor space, and the impeller drive bearing device is isolated from water and water-receiving materials, and the failure rate is low. The spiral sand washer has a strong cleaning capability and is often deployed in a large sand production line. Southeast Asia exports sand The countries that export sand in Southeast Asia are mainly Malaysia, Vietnam, Indonesia and Cambodia. Among them, the sand in Malaysia is…
More >
According to the "Cambodian Minerals Law", mining in Cambodia is divided into individual mining and industrial mining. Individual mining means that the local residents in the mining area carry out manual mining on their own land, and it must be less than 7 people. No mechanical equipment and explosives are allowed. The depth is not allowed to exceed 20 meters. The purpose is to help people improve their lives. The mining certificate is issued by the mineral bureau of the province where it is located and is valid for one year. Industrial mining is issued by the Ministry of Mines and Energy. It is divided into exploration licenses and mining licenses. Only companies with certain funds and technologies are eligible to obtain them. At present, most companies only have exploration licenses. Fees for small mining farms Individual mining requires buying land, or renting land, and then buying sand making and sand washing equipment. Generally, a small sand and gravel plant costs 80,000 to 200,000 US dollars. The establishment of a sand washing plant must require legal procedures. Recently, a team…
More >
The screening and washing machine is used for washing, dewatering and grading of gravel aggregates, piling mud and silica sand. The machine has a compact structure, small footprint, can be quickly installed and moved, and can quickly start working. The combined screening equipment can be equipped with a crusher Sand making machine, used in sand factory and metal ore production. Advantages 1. One machine completes various operations such as cleaning, screening, recycling and dehydration. 2. The rear part of the screen surface adopts a plate structure to form a water reservoir, and an additional weir is added to extend the cleaning time and the material cleaning effect is better. 3. The overall screen surface lengthens, which is more conducive to screening. 4. Equipped with a fine sand recovery device to effectively recover the fine sand lost during the washing process. Structure 1. Sand washing and dewatering screen 2. Ordinary motor 3. Separation and recovery device 4. Support spring 5. Water tank under sieve 6. Rubber hose 7. Slag paddle pump 8. Slurry pump motor Working Principle The materials are evenly…
More >
The single-layer vibrating screen can screen two different grades of materials when screening materials. The assembly type and welding type of the high-frequency linear vibrating screen have certain differences in product installation and components. The assembly type uses a circular tube structure motor beam, which can effectively avoid welding stress. Name: High frequency linear vibrating screen [Structure Mode]: Assembled structure Feeding granularity: ≤10mm Processing capacity: 60-180t / h Applicable Industry: 1. Wet sand production line, sand washing, desilting and dewatering operations. 2. Coal slime recovery and other operations. 3. Dry discharge and dry pile operation of tailings in the dressing plant. 4. Other industries related to dehydration, sludge removal, and mediating. SINGLE LAYER VIBRATION SCREEN FEATURES 1. The main body adopts an assembled structure to reduce welding connections and effectively control cracks caused by welding stress. 2. The motor installation beam uses a round tube structure with even torque distribution. 3. The vibration source selects a 4-level vibration motor to achieve high-frequency vibration, which is more conducive to material dehydration and mud removal operations. 4. The amplitude can be adjusted…
More >
With the development of the economy, the world's demand for sand and gravel continues to increase. The river gravel washing plant designed by LZZG acts in different sand making environments. Cobblestone sand production line generally consists of vibrating feeder, crusher, sand making machine, belt conveyor, circular vibrating screen, sand washing machine, dewatering screen, and other equipment. Pebble crushing and washing plant Directly mined stone or produced sand contains more impurities, which is not conducive to sales. Therefore, many cobblestone sand production lines will be equipped with sand washing machine equipment. Under normal circumstances, the vibratory screening equipment already has some functions in the soil, without the need for sand washing equipment. However, if gravel aggregates with high cleanliness requirements are required, it is often necessary to equip the sand washing machine or bucket wheel to type sand. Sand Washing Machine. working process Jaw Crusher —- Coarse Crushing Cone crusher (impact crusher) —- secondary crushing Sand making machine —- Fine crushed sand making Vibrating screen —- screening Sand washing machine —- cleaning Dewatering screen —- drying Vibration feeder-finished product Requirements…
More >
Global sand and gravel washing machine demand is growing. It is estimated that the global sand and gravel output is about 50 billion tons. Based on the total population of 7.7 billion in the world, the per capita sand and gravel consumption is about 6.5 tons. In terms of regions, Asia accounts for 66% of global sand and gravel production. An aggregate washing plant Looking ahead to 2030, the global sand and gravel industry trend is still positive. Population growth (8.5 billion people in 2030), economic development, and global urbanization (expected to reach 60% in 2030), the three major factors jointly promote the growth of the sand and gravel industry. Global sand and gravel production is expected to reach 60 billion tons in 2030. [caption id="attachment_4656" align="alignnone" width="400"] Aggregate washing machines[/caption] Colombia sand aggregate production Colombia currently has a total output of about 147 million tons of sand and gravel, with a per capita consumption of about 3 tons. The main challenge facing the country's sand and gravel industry is that half of the country's sand and gravel is illegally…
More >
This set of sand washing plant is manufactured for a sand making plant in Peru. The output capacity is 100 tons per hour, and the sand washing plant is used for ore sand washing. Low cost, less equipment wear, durability, low water consumption, low noise during operation, and meet national environmental protection production requirements. On the other hand, the structure of the sand washer is relatively simple. The impeller transmission bearing device of the equipment is isolated from the water-receiving material, which prevents the bearing from being damaged due to water immersion and pollutants. Therefore, it can be applied to various working environments and has a good Layout design, good sealing. Machinery shipped this time: round vibrating screen, wheel sand washer, spiral sand washer, dewatering screen, fine sand recycling machine, etc. This set of sand production plant: [Production capacity] 50-200t / h [Finished product size] 0-5mm [Composition equipment]: Vibrating feeder, jaw crusher, sand making machine, vibrating screen, sand washing machine, belt conveyor, etc. Sand-making production line process The materials from the sand making machine are returned to the vibrating screen…
More >
Cage drum screen is another new generation of screening equipment after plane vibrating screen and cantilever vibrating screen. It is widely used for screening various solid fuels with a particle size below 400mm. Cage drum screen has many advantages such as wide adaptability of coal type, simple coal feeding mode, high screening efficiency, large screen component, low energy consumption, low noise, strong sealing performance, long service life, small maintenance, and convenient maintenance. Its screening capacity is 150t / h - 420t / h, or even higher. How the device works The main structure of the cage drum screen is a screening cylinder, which is a screen composed of a plurality of annular flat steels. The whole is inclined with the ground plane, and the outside is sealed by a sealing spacer to prevent environmental pollution. Through the variable speed deceleration system, the screening cylinder is rotated at a certain rotation speed, and the coal is separated from the top to the bottom through the screening cylinder, and the fine material is discharged from the lower part of the front end…
More >
The mechanical mud desander mainly has a vibrating screen. The mud passes through the vibrating screen to destroy the structure of the mud, so that the cuttings and sand slide down from the sieve, and the mud flows out from the sieve. The sandstone vibrating screen uses the vibration exciter as the vibration source, and the high-efficiency soft link device is applied. When the equipment works to generate vibration, the equipment is protected. The unique structure screen will not be blocked, and the tilt of the screen surface of the equipment can be Adjusted by a unique adjustment device, the service life is greatly improved, resulting in high practical value. Sand and gravel sieve can sift many materials, such as ore, aluminum powder, copper powder, sand, ore, alloy powder, sand, stone, abrasive powder, refractory material, limestone, quartz sand, and other materials. The hydraulic mud desiler has a mud cyclone desander, which first pumps the mud into a funnel container by a sand pump. The pumping direction is directed along the tangential line to the inner wall of the container.…
More >
Although lignite is low in mining cost, it is usually only used on site because of its high water content and low energy density, which is not suitable for transportation or trade. In addition, with the slowdown in China's consumption growth, coupled with the vigorous development of US shale oil, the international coal market price is lower, which also makes the situation of relatively high-cost hard coal power plants relatively prosperous. Vibrating screen can be used in Lignite quality improvement lignite coal vibrating screen c has high moisture and ash content, low calorific value, easy weathering in the air, and is not conducive to long-distance transportation. When used directly as a fuel, the combustion efficiency is low, and the greenhouse gas emissions are high and the pollution is serious, which has been greatly limited for a long time. The upgrading of lignite refers to the reduction of moisture in lignite by thermophysical or thermochemical methods, and the increase of the calorific value of the product, which is convenient for transportation, high heat utilization efficiency and low pollution. In Germany, coal-fired…
More >
Compound fertilizer equipment drum screening machine is common equipment used in the production of compound fertilizer. It is mainly used for the separation of finished products and return materials. It can also realize the classification of finished products and make the finished products evenly classified. The combination screen is convenient for maintenance and replacement. The machine has a simple structure, convenient operation, and stable operation. Inorganic fertilizer is a compound fertilizer such as various nitrogen, phosphorus, potassium or compound fertilizers. Fertilizers are commonly used in planting. Organic fertilizer is farmyard manure such as manure, decaying animal carcasses or decomposed plants. Feature of rotary trommel screen The screen hole is not easy to block. Running smoothly and the noise is low. The structure is simple and the maintenance is convenient. The trommel drum cylinder can be closed, and easy to collect dust. Various plate and mesh sizes. Screen drums made to customer specification. Preparation before the drum screen is run 1. After the components of the drum screen are installed, after the inspection is passed, the test run can be carried…
More >
The spiral sand washing machine is a multifunctional washing machine that combines the functions of sand washing, sand and stone dehydration, and recycling. It is designed and developed by our company for the stone powder and the material containing high mud content in the sand and gravel washing industry. The structure of the equipment is reasonable, and the tailings dry sieve is used together with the double-screw sand washing machine to set up more than 300 tons per hour. It effectively solves the shortcomings of a large amount of fine sand loss and the unclean cleaning of the traditional spiral sand washing machine. Through the washing and selection of the equipment, the finished sand grading can be made more reasonable, and the customer's quality requirements for the sand content can be satisfied. spiral sand washing machine parameter [Feed size]: ≤10mm [Processing amount]: 30-240t/h [Applicable materials]: River pebble, granite, limestone, basalt stone, coal gangue, weathered sand, river sand, yellow sand, and many other materials. [Scope of application]: This equipment has been widely used in various industries such as sand mining yards,…
More >
Mining trommel screen is screening equipment developed for power plants, coking plants, building materials, metallurgy, chemical industry, mining, and other industries with large processing capacity, high screening efficiency and no plugging. Trommel screen overcomes the circular vibrating screen. And the linear vibrating screen has the problem of screen blockage when screening wet materials, which improves the output and reliability of the screening system. Mine drum screen working principle Australia high quality trommel screen parameters After the broken stone enters the drum, the material is sieved by the centrifugal force of the rotation of the drum and the elimination effect. The stone with large grain size flows forward along with the inclination of the drum and is gradually screened out through the screen of different meshes, and the granularity is not large. After the stone material is sieved out, it falls into the respective funnels. The materials are screened out one by one through different mesh screens and then dropped into the belt conveyor through the funnel and sent to the finished material yard. Trommel screen for occasions: 1. Stone yard…
More >
Buy vibratory screen trommel screen with low cost in Pakistan GP tailing dewatering screen is specially designed for mineral tailing recycling, which combines the characteristics of mineral tailing with high frequency sieve. The dewatering unit consists of hydrocyclones, linear motion vibrating screen, slurry pump and attachments. The rotary screen was designed to minimize setup time and be easy and convenient to service. We have perfected the ability to size and customize trommel screens with different materials to suit the application, such as the updated product compact sand washer. Since the first cooperation between the two parties in 2003, there have been many cooperation histories, including technological transformation projects, cement production lines, waste heat power generation, and grinding stations. The successful signing of this project has important significance for Pakistan ATTOCK Cement Company to increase production capacity and expand its market share in Pakistan. As the general contractor, Hefei Academy will send an excellent project team, as always, to provide the best service for Pakistan ATTOCK Cement Company, and in strict accordance with the contract, quality and quantity are completed.
More >
Vietnam needs about 100 million cubic meters of sand each year for construction projects in the country. But the domestic supply of natural sand was nearing an end and could be depleted in five years due to excessive exploitation, the Vietnam News reported recently. Vietnam will need more artificial sand instead nature sand. The artificial sand can be manufactured by crushing certain types of rocks, which can be found in southern Vietnam. The artificial sand should be washed by sand washing plant before sell. The sand washing plant can remove impurities such as dust from sand products. We researched and produced a series of the sand washing plant, such as DS Series Multi-Function Sand Washer, Spiral sand washing and recycling machine. The plant is consists of the conveyor, sand washing machine, dewatering screen with a cyclone. the feature of the lzzg sand washing plant 1. Multiple functions: washing, screening, dewatering, and recycling; 2. Recovering 0.16-3mm fine sand; 3. 95% of sand can be recycled; 4. Moisture content within 15%, mud content of less than 2% 5. Solving sedimentation tank cleaning problem, higher…
